90HP 4WD Tractor For Daily Field Operations
Details
This 90HP 4WD tractor features electro-hydraulic lifting for easier implement control, a reinforced maintenance-free front axle for stable 4WD operation, and a TF reinforced quick hitch for faster implement changes. The reinforced guard plate helps protect key components during field work.
Category
Small Tractor
Share to
Description


Ⅰ.Products Description

product-1250-1000

This 90HP 4WD tractor is designed for routine farm work such as plowing, tillage, transport, and PTO-driven operations. It uses a turbocharged YUNNEI or YUCHAI diesel engine with a rated output of 66.2 kW, providing stable power for medium to heavy workloads.





Ⅱ.Technical Parameters







Parameter Items 904-B
Overall Drive Type ■4WD
Overall External Dimensions (Length × Width × Height and Position) (mm) 4000×1850×2650 (Safety Frame)
3645×1780×2700 (Cab)
Wheelbase or Track Ground Contact Length (mm) 2050
Wheel Track (Front/Rear) or Gauge (mm) 1200-1450/1200-1700
Number of Gears (Forward/Reverse) 12+12
Engine Manufacturer Yunnei Turbocharged / Yuchai
Engine Model YN38TBE4/YCF39110-T481
Engine Rated Power (kW) 66.2
Tire Model (Front/Rear) (Optional) 9.5-24/14.9-30
Hydraulic Oil Pump Model for Working Device BTB320
Number of Hydraulic Output Groups (Optional) (Group) 2/3
PTO Standard Speed (r/min) 540/760


Ⅲ.Product Details

product-1000-801
01.

Reinforced Maintenance-free Front Axle

The reinforced front axle is designed for 4WD operation and higher front loads. Its maintenance-free structure reduces daily servicing requirements and supports stable operation when working with heavy rear or front-mounted implements.

02.

Reinforced Guard Plate

A reinforced guard plate is installed under the tractor to protect key components from stones, soil clods, and field debris. This is especially useful when working on uneven ground or post-harvest fields, reducing the risk of damage.

product-1250-1000
product-1000-800
03.

Electro-hydraulic Lifting System

The electro-hydraulic lifting system allows operators to control implement lifting and lowering with less manual effort. Response is quicker than mechanical control, which helps when frequent adjustments are needed during field work.

04.

TF Reinforced Quick Hitch

The TF reinforced quick hitch simplifies implement attachment and removal. Operators can change implements faster, which is practical when switching between tasks during the same workday.

The tractor supports 540/760 rpm PTO speeds and offers optional 2 or 3 hydraulic output groups. This setup allows it to work with common implements such as plows, rotary tillers, seeders, trailers, and balers. The BTB320 hydraulic pump provides consistent oil supply during operation.

product-1000-800



IV.one-stop Shopping For Agricultural Tractors



product-1000-1000



Ⅴ.Packing & Delivery

product-1000-563



Ⅵ.Company Introduction

Woye Heavy Industry is a professional enterprise integrating R&D, production, manufacturing and global distribution of mid-to-high-end agricultural tractors. Located in Weifang, Shandong (China's "City of Power"), we hold professional production qualifications, ensuring standardized operations.

As a professional tractor producer, manufacturer and distributor, Woye relies on rich industry experience and cooperation withwell-known parts brands to build a trusted global agricultural equipment brand.

product-1739-1000





Ⅶ.FAQ

Q: 1. Are you a trading company or a manufacturer?

A: We are a distinguished manufacturer with a professional edge.

Q: 2. What is your delivery time?

A: For regular stocked items, expect delivery within 7-15 days. For custom or out-of-stock goods, anticipate a delivery timeline of 30-60 days, contingent on order volume.

Q: 3. What are your payment terms?

A: A 30% down payment is required, with the remaining balance due before shipment.

Q: 4. What is your minimum order quantity?

A: Minimum order quantities vary by product. Please contact us for specific details.

Q: 5. How to install the machines after they arrive?

A: Upon receipt of the goods, we will provide an installation video specific to the product. Follow the video for seamless installation.

Q: 6. Can your products be customized?

A: Customization is available, provided certain conditions are met.

Q: 7. How do you ensure the quality of your product?

A: Our expert team conducts rigorous quality inspections to ensure superior standards
